Davies Craig Electric Water Pump - EWP150 Alloy & LCD Controller Combo 24V - 8971

Davies Craig Electric Water Pump

Muscle up your engine cooling system with the Davies Craig EWP150 Alloy 24V Electric Water Pump and the LCD EWP/Fan Digital Controller. Like all EWPs, this advanced unit is designed for remote mounting in the engine bay to satisfy those higher horsepower, turbocharged, supercharged and ‘worked’ engines which develop excessive heat. The compact EWP150 Alloy unit is manufactured with AN-16 internal inlet and outlet threads for neat, tight screw-in fitting applications. This rugged alloy hi-flow electric water pump is designed to complement or replace the engine’s existing mechanical water pump. This essential performance part increases power to your vehicle’s drive wheels and improves coolant temperature control.

The EWP150 is a universal, do-it-yourself, easy installation fitment to engines up to seven litres. By removing the parasitic power losses of belt-driven water pumps, the EWP150 releases up to 10kW (13hp) of extra power, increased torque and fuel savings. Combine it with the LCD EWP/Fan Digital Controller and the pump continues to run after you’ve switched off, eliminating “heat soak” and extending engine life.

The EWP150 and LCD EWP/Fan Digital Controller Combo Kit is the most economical way to increase horsepower and save on fuel consumption whilst caring for your engine. EWP Installation Options:

• Installing an EWP as an auxiliary pump
• Disabling mechanical water pump
• Disengaged mechanical water pump (recommended)
• Removed mechanical water pump (ideal)

EWP & Fan digital controller - 12 & 24 VOLT

The EWP & Fan Digital Controller (Part #8002) is Australian designed and as part Davies, Craig's continuous improvement program this advanced Digital Controller boasts a suite of enhancements. The updated Digital Controller now has two specific functions. This unique Controller will now manage the operation of the EWP by varying the speed of the EWP in response to the temperature of the engine and manage control of your electric engine fan. The Controller has a push-button on the facia panel that offers target temperatures: Singular degrees from 40°C to 110°C .

The LCD Digital Controller will now operate the engine’s electric fan automatically once the engine has reached +3°C above the target temperature. A significant benefit too is the Controller allows the EWP to run on after ignition shutdown to reduce heat soak. It is recommended that engine operational temperatures be checked with manufacturer.

Features:

• Black & White Numerical Screen
• Celsius or Fahrenheit display option
• Warning Alarms:
• - Plus 10°C (14°F) set/target temperature
• - Under temp 40°C after 5 mins
• - Temp sensor error
• - Over or under voltage
• - EWP error
• Select any set temp range from 40°C to 110°C
• Set / targeted temperature memory
• Override feature to assist bleeding EWP & fail safe
• Input voltage display
• Compatible with billeted style Electric Water Pumps

When changing the water pump, we also recommend swapping out your coolant hoses, hose clamps and any other cooling related service parts. To maximise the longevity of your cooling system, its a good idea to run a coolant flush through the system too. Use the rego search function on the Repco website, or head into your local Repco store to view our range of water pumps to suit your vehicle.
